D3 MINI

  • MINI in size, powerful inside, Qualcomm hexa-core 2.4GHz processor: 3GB RAM – 32GB ROM / 2.4G + 5G Dual-band Wi-Fi / SUNMI OS 4.0 performance improvement.
  • UFS 2.2: Quick response and cache loading thanks to its high read and write speed. A UFS device is also secured and reliable for your data.
  • Built-in battery: Featuring 4-hour runtime, the battery ensures stable device running under voltage fluctuation and power outage. SUNMI OS 4.0 can learn how do you use the battery to extend the battery life.
  • D3 MINI is small in size, light in weight and comes with a 10.1 inch screen and saves more space.
  • 4″ IPS capacitive touchscreen secondary display: Secondary display comes with a capacitive touchscreen with high responsiveness.
  • Rubber seals added to protect the printer: Protect the printer from dust, liquid among other foreign objects.
Categories: ,

Description

  • Convenience store: Scan or tap to pay, get the receipts, and go. Your customers would enjoy shopping in your store more with the quick payment experience.
  • Food truck: Long battery run-time designed for your on-the-go business. The battery in D3 MINI 58mm version can power the device and your operations. Less downtime, more sales.
  • Food stall: The smooth-running D3 MINI will help you take care of customers flocking to your busy stall and deliver an experience that both you and your customers would love.

Additional information

OS

SUNMI OS
(based on Android 13)
Processor

Qualcomm hexa-core, up to 2.4GHz
Memory

3GB RAM+32GB ROM
Display

Main: 10.1" IPS HD, 800*1280, 300nits; 10-point capacitive touch display；
Secondary: 2.4" seven-segment display.
Printer

Built-in 58mm thermal printer
Print speed: up to 100 mm/s
Service life: 50Km
Paper roll OD: 50mm
Card Reader

Support TypeA&B card, Mifare card, Felica card;
Comply with ISO/IEC 14443, ISO 15693 standards;
Read distance 0-4cm
Scanner

A 1MP built-in scanner for 1D/2D barcode reading
PSAM Card Slot

2*PSAM, 3.0V supported
SIM Card Slot

2*SIM, support 1.8V/3.0V
Speaker

1* 3W
Network

2G&3G&4G
Wi-Fi

2.4GHz & 5GHz
IEEE 802.11 a/b/g/n/ac supported
Bluetooth

Bluetooth 2.1/3.0/4.2/5.0
and BLE supported
Indicator Light

Blue (Power)
Button

1*Power button (lock screen)
1*Reset button (hidden)
Ports

3*USB TypeA port
1*RJ11 serial port
1*RJ12 cash drawer port
1*RJ45 LAN port
1*audio jack
1*power port
1*MicroUSB debug port (hidden)
Battery

Built-in battery
2600mAh
(Only the 58mm 4G version comes with a battery included in the package.)
Power Adapter

Input: AC 100~240V/1.5A
Output: DC 24V/1.5A/36W
Weight

1.1kg
Environment

Operating temp: 0°C~40°C
Storage temp: -20°C～60°C
Dimensions (L*W*H)

250*213*91mm
